SVAR React Gantt is a customizable, high-performance Gantt chart component written in React. It offers a developer-friendly API, full TypeScript support, React 19 compatibility, and flexible CSS styling.
The component supports multiple task types, dependencies, custom time scales, and light/dark themes. It is designed to handle thousands of tasks efficiently (see demo with 10k tasks).
Interactive, drag-and-drop interface allows users to add, edit, and organize tasks and dependencies directly on the timeline or through a simple task edit form.
✨ Core Features
SVAR React Gantt gives you the baseline of project planning: an interactive timeline, a task grid, intuitive UI for task management, and backend bindings — typed end to end and ready for React 19 and Next.js.
Timeline
- Interactive drag-and-drop timeline
- Task and dependency visualization
- Hierarchical view of subtasks
- Task progress shown on taskbars
- Configurable time scale: hours, days, weeks, sprints or stages
- Flexible time units: hours and minutes
- Weekend and holiday highlighting
- Zooming with scroll
- The ability to drag tasks from a backlog
Grid
- Customizable grid columns
- Sorting tasks in the grid
- Reorder tasks in the grid
- Task filtering, including natural language search
- Custom HTML in grid cells
- In-cell editing in the grid
Task interaction
- Customizable task edit form
- Toolbar and context menu
- Tooltips for taskbars and links
- Hotkeys for common actions
Data & performance
- Virtualization for large data sets
- Dynamic loading of sub-tasks
- RestDataProvider for REST backend binding
- Real-time updates from the server
UI & tooling
- Light and dark themes
- Localization
- Full TypeScript support
- AI tools for coding agents: MCP server, skills, and flat context files
🚀 PRO Edition
In addition to free, open-source core, SVAR React Gantt offers the PRO edition with additional features and automation logic:
Scheduling & constraints
- Auto-scheduling: FS, SS, FF, SF, and lag
- Constraints (6 types)
- Critical path and deadlines
- Manual and inactive tasks
Calendars & resources
- Working time calendar (non-linear time scale), with individual calendars for tasks and resources
- Resource-driven scheduling
- Resource load chart and histogram
- Drag-and-drop resource assignment
Tracking
- Baselines, progress line, and S-curve
- Slack (float) visualization
Advanced task management
- Task grouping
- Rollups
- Split tasks
- Summary tasks automation
- Unscheduled tasks
- WBS codes support
Layout & data
- Sub-grid panel and placeholder row
- Undo/redo
- Vertical markers
- Export to PDF, PNG, Excel (including resources and assignments)
- MS Project import/export
Visit the pricing page for full feature comparison and free trial.
Check out the demos to see all SVAR React Gantt features in action.
:hammer_and_wrench: How to Use
To start using SVAR React Gantt, simply import the package and include the desired component in your React file:
import { Gantt } from '@svar-ui/react-gantt';
import '@svar-ui/react-gantt/all.css';
export default function MyComponent() {
const tasks = [
{
id: 20,
text: 'New Task',
start: new Date(2024, 5, 11),
end: new Date(2024, 6, 12),
duration: 1,
progress: 2,
type: 'task',
lazy: false,
},
{
id: 47,
text: '[1] Master project',
start: new Date(2024, 5, 12),
end: new Date(2024, 7, 12),
duration: 8,
progress: 0,
parent: 0,
type: 'summary',
},
];
return <Gantt tasks={tasks} />;
}
See the getting started guide to learn how to configure data sources, customize columns, and enable editing.
You'll also find integration guides for:
⭐ Show Your Support
If SVAR React Gantt helps your project, consider giving us a star! It helps other developers discover this library and motivates us to keep improving.
:speech_balloon: Need Help?
Post an Issue or use our community forum.
